SafeAccess Rail for suspended work at height

SafeAccess Rail from Fallprotec is a rail system for suspended work during facade maintenance and cleaning. The system can be adapted to the building’s shape and provides access to facades on buildings with heights ranging from 5 to 300 meters.

SafeAccess can be installed at entrances, atriums, courtyards, and main facades. The screen can be bent according to the building’s geometry and powder-coated in any RAL color. For sloped facades, Climbing SafeAccess features a high-strength stainless steel chain integrated into the screen. An active climbing system with ball wheels enables movement in slopes up to 70°. The system can be used with manual, motorized, or battery-powered sleds and is compatible with several solutions for suspended work.

Areas of use

SafeAccess is used for suspended access during maintenance and cleaning of façades on, among other things, high-rise buildings, airports, hospitals, commercial buildings, shopping centres, monuments and architecturally distinctive buildings.

Specification

• Use: Hanging access, facade maintenance and cleaning
• Building height: 5 to 300 m
• Material: aluminium
• Weight: 5 kg/m
• Surface treatment: Anodized or powder-coated with resistance to marine environment
• Color: Can be powder coated in any RAL color
• Scenography: Can be bent around facades and interior structures
• Maximum tilt with Climbing SafeAccess: 70°
• Climbing system: Chain-based system with high-strength chain made of stainless steel
• Trolleys: Manual, motor-driven or battery-powered
• Maximum distance between consoles: 3 m
• Standard: EN 1808:2015, EN 795:2012 Type D, BS 8610:2017, ASME/ANSI A120.1-2014 and IWCA I-14.1

FAQ

On which façades can SafeAccess Rail be used?

The system can be adapted to both vertical and inclined façades and installed in, for example, atriums, courtyards and entrances. Climbing SafeAccess can handle slopes of up to 70°.

What equipment can be used with SafeAccess?

The system is compatible with, among other things, repair work techniques, RopeClimber, suspended work platforms, traversing ladders, auxiliary winches and roofcars.

Can SafeAccess be adapted to suit the building's design?

Yes. The rail can be bent according to the building’s geometry, the brackets can be designed according to the installation, and the rail can be powder-coated in the desired RAL color.
